Starter relay¶

Inspection of starter relay¶

Location: In the luggage compartment on the left side.

1. Inspect relay continuity.

   1. Using an ohmmeter, check that there is continuity between terminals 1 and 3.
   2. Check that there is no continuity between terminals 2 and 4.

   If continuity is not as specified, replace the relay.



2. Inspect relay operation.

   1. Apply battery voltage across terminals 1 and 3.
   2. Using an ohmmeter, check that there is continuity between terminals 2 and 4.

   If operation is not as specified, replace the relay.
