Oil pump

Removal of oil pump

Hint

When repairing the oil pump, the oil pan and strainer should be removed and cleaned.

  1. Disconnect cable from negative terminal of battery.

    Caution

    Work must be started after approx. 20 seconds or longer from the time the ignition switch is turned to the LOCK position and the negative (–) terminal cable is disconnected from the battery.

  2. Drain engine oil. (See Oil pressure check)

  3. Remove engine under covers.
  4. Remove RH engine hood side panel.

  5. Remove suspension upper brace.

  6. Remove cruise control actuator (w/ cruise control system) and accelerator linkage.

  7. Remove front exhaust pipe.

  8. (3S-GTE) Remove A/C compressor without disconnecting hoses. (See Intercooler › Removal of intercooler, step 12)

  9. (5S-FE) Remove A/C belt idler pulley. (See Cylinder block (5S-FE) › Removal of engine, step 31)
  10. (3S-GTE) Remove catalytic converter. (See Cylinder head (3S-GTE) › Removal of cylinder head, step 14)
  11. (3S-GTE) Remove intercooler. (See Intercooler, steps 4, 5, 7–13)

  12. Remove stiffener plate.

    Remove the three bolts and stiffener plate.

  13. Disconnect turbocharger oil outlet hose from oil pan.

  14. Remove oil pan.

    1. Remove the dipstick.

    2. Remove the seventeen bolts and two nuts.

    3. Insert the blade of SST between the cylinder block and oil pan, cut off applied sealer and remove the oil pan.

      SST 09032-00100

      Notice

      • Do not use SST for the oil pump body side and rear oil seal retainer.
      • Be careful not to damage the oil pan flange.

  15. Remove oil strainer and baffle plate.

    Remove the two bolts, two nuts, oil strainer, baffle plate and gasket.

  16. Suspend engine with engine chain hoist.

  17. Remove timing belt.

  18. Remove No.2 idler pulley, crankshaft timing pulley and oil pump pulley.

  19. Remove oil pump.

    1. Remove the twelve bolts.

    2. Using a plastic-faced, remove the oil pump by careful tapping the oil pump body.

    3. Remove the gasket.

Components

Disassembly of oil pump

(See Removal of oil pump)

  1. Remove relief valve.

    1. Using snap ring pliers, remove the snap ring.
    2. Remove the retainer, spring and relief valve.

  2. Remove drive and driven rotors.

    Remove the two bolts, pump body cover, O-ring, the drive and driven rotors.

Inspection of oil pump

  1. Inspect relief valve.

    Coat the valve with engine oil and check that it falls smoothly into the valve hole by its own weight.

    If it doesn't, replace the relief valve. If necessary, replace the oil pump assembly.

  2. Inspect drive and driven rotors.

    A. Inspect rotor body clearance

    Using a feeler gauge, measure the clearance between the driven rotor and body.

    Standard body clearance: 0.100 – 0.160 mm (0.0039 – 0.0063 in.)

    Maximum body clearance: 0.20 mm (0.0079 in.)

    If the body clearance is greater than maximum, replace the rotors as a set. If necessary, replace the oil pump assembly.

    B. Inspect rotor tip clearance

    Using a feeler gauge, measure the clearance between the drive and driven rotors.

    Standard tip clearance: 0.040 – 0.160 mm (0.0016 – 0.0063 in.)

    Maximum tip clearance: 0.20 mm (0.0079 in.)

    If the tip clearance is greater than maximum, replace the rotors as a set.

Replacement of oil pump oil seal

  1. Remove oil seal.

    Using a screwdriver, pry out the oil seal.

  2. Install oil seal.

    1. Using SST and a hammer, tap in a new oil seal until its surface is flush with the oil pump cover edge.

      SST 09620-30010 (09627-30010, 09631-00020)

    2. Apply MP grease to the oil seal lip.

Replacement of crankshaft front oil seal

(See Cylinder block (3S-GTE) › Replacement of crankshaft oil seals)

Assembly of oil pump

(See Removal of oil pump)

  1. Install drive and driven rotors.

    1. Place the drive and driven rotors into pump body with the marks facing the pump body cover side.

    2. Install a new O-ring to the pump body.

    3. Install the pump body cover with the two bolts.

      Torque: 90 kg-cm (78 in.-lb, 8.8 N·m)

  2. Install relief valve.

    1. Insert the relief valve, spring and retainer into the pump body hole.
    2. Using snap ring pliers, install the snap ring.

Installation of oil pump

(See Oil pump)

  1. Install oil pump.

    Install a new gasket and the oil pump with the twelve bolts.

    Torque:

    • 3S-GTE – 80 kg-cm (69 in.-lb, 7.8 N·m)
    • 5S-FE – 95 kg-cm (82 in.-lb, 9.3 N·m)

    Hint

    Each bolt length is indicated in the figure.

    Bolt length:

    • Long bolt – 35 mm (1.38 in.)
    • Others – 25 mm (0.98 in.)

  2. Install oil pump pulley, crankshaft timing pulley and No.2 idler pulley.

  3. Install timing belt.

  4. Remove engine chain hoist from engine.

  5. Install baffle plate and oil strainer.

    Install a new gasket, the baffle plate and the oil strainer with the two bolts and two nuts.

    Torque: 55 kg-cm (48 in.-lb, 5.4 N·m)

  6. Install oil pan.

    1. Remove any old packing (FIPG) material and be careful not to drop any oil on the contact surfaces of the oil pan and cylinder block.

      • Using a razor blade and gasket scraper, remove all the old packing (FIPG) material from the gasket surfaces and sealing groove.
      • Thoroughly clean all components to remove all the loose material.
      • Using a non-residue solvent, clean both sealing surfaces.

      Notice

      Do not use a solvent which will affect the painted surfaces.

    2. Apply seal packing to the oil pan as shown in the figure.

      Seal packing: Part No. 08826-00080 or equivalent

      • Install a nozzle that has been cut to a 3 – 5 mm (0.12 – 0.20 in.) opening.

      Hint

      Avoid applying an excessive amount to the surface. Be particularly careful near oil passages.

      • Parts must be assembled within 5 minutes of application. Otherwise the material must be removed and reapplied.
      • Immediately remove nozzle from the tube and reinstall cap.

    3. Install the oil pan with the seventeen bolts and four nuts.

      Torque: 55 kg-cm (48 in.-lb, 5.4 N·m)

    4. Install the dipstick.

  7. Connect turbocharger oil outlet hose to oil pan.

  8. Install stiffener plate.

    Install the stiffener plate with the two bolts.

    Torque: 380 kg-cm (27 ft-lb, 37 N·m)

  9. (3S-GTE) Install intercooler. (See Intercooler › Installation of intercooler, steps 2–8, 10, 11)

  10. (3S-GTE) Install catalytic converter. (See Cylinder head (3S-GTE) › Installation of cylinder head, step 28)
  11. (3S-GTE) Install A/C compressor. (See Intercooler › Installation of intercooler, step 3)
  12. (5S-FE) Install A/C belt idler pulley. (See Cylinder block (5S-FE) › Installation of engine, step 13)

  13. Install front exhaust pipe.

  14. Install cruise control actuator (w/ cruise control system) and accelerator linkage.

  15. Install suspension upper brace.

  16. Connect cable to negative terminal of battery.

  17. Fill with engine oil. (See Replacement of engine oil and oil filter)
  18. Start engine and check for leaks.
  19. Recheck engine oil level. (See Oil pressure check)
  20. Install RH engine hood side panel.
